Hot-Dip Galvanized U-Channel Steel Support Bracket

The Hot-Dip Galvanized U-Channel Steel Support Bracket from ZHONGTIAN is designed for long-term photovoltaic mounting applications. Made from Q235B or Q355B hot-rolled U-channel steel and galvanized according to GB/T 13912, it combines corrosion resistance, structural strength, adjustable installation, and factory customization. It is suitable for ground-mounted solar farms, agricultural PV, fishing PV, rooftop systems, and solar carports.

Corrosion Protection

Hot-Dip Galvanizing

The Hot-Dip Galvanized U-Channel Steel Support Bracket uses a hot-dip galvanized coating that forms a zinc-iron alloy layer with the steel substrate. The coating provides strong adhesion and cathodic protection against minor surface damage.

The supplied data indicates 500+ hours of salt spray resistance and long-term protection in coastal, salt-alkali, acid-rain, and humid environments. Under suitable conditions, the service life can reach approximately 25 years with reduced corrosion maintenance.

Processing Durability

The galvanized components support factory cutting, bending, punching, and other processing without easily peeling the protective coating. Pre-processing reduces onsite modification and the need for secondary anti-corrosion treatment.

Structural Performance

Steel Materials

Q235B and Q355B hot-rolled U-channel steel are available according to project loading requirements. The U-shaped profile provides good bending and torsional resistance for photovoltaic support structures.

Load Capacity

The structure can be engineered for strong wind, heavy snow, and other environmental loads. The supplied data indicates a single-column load capacity of up to 1.5 tons under specified conditions.

Temperature Range

The supplied operating range is approximately -40°C to 120°C. Actual structural design should consider local temperature, wind, snow, foundation, and installation conditions.

Adjustable Installation

Tilt Adjustment

The system supports multiple tilt positions from 10° to 60°, allowing the mounting angle to be adjusted according to project location and solar conditions. The supplied project data indicates that optimized angles can potentially improve annual generation by 5%–8%, depending on site conditions.

Module Compatibility

The U-channel sliding structure supports different photovoltaic module layouts and can be used with both monofacial and bifacial modules. Module spacing and mounting positions can be adjusted during installation.

Terrain Adaptation

The modular structure can accommodate flat ground, sloped terrain, agricultural PV, fishing PV, and other sites with varying elevation or foundation conditions.

Installation Method

Bolt Assembly

The Hot-Dip Galvanized U-Channel Steel Support Bracket uses standardized punched holes and stainless-steel fasteners for bolt-connected installation. This reduces onsite welding and simplifies assembly.

Under suitable project conditions, the standardized installation method can shorten construction time by more than 30%.

Factory Pre-Processing

ZHONGTIAN can complete cutting, punching, bending, and selected pre-assembly operations before shipment. This helps reduce onsite fabrication and improves installation efficiency.

Project Applications

Ground-Mounted PV

Single-column and double-column configurations can be selected according to module size, foundation spacing, wind load, and snow load.

Agricultural and Fishing PV

Elevated structures can provide the required clearance for agricultural activities or water-based photovoltaic projects while maintaining structural stability.

Rooftop and Carport PV

Lightweight rooftop structures and integrated solar carport configurations can be customized according to roof conditions, parking layouts, module dimensions, and structural requirements.

Lifecycle Cost

Lower Maintenance

Hot-dip galvanizing reduces the need for regular rust removal and repainting compared with basic cold-galvanized structures. This can reduce long-term maintenance work for large solar projects.

Long-Term Cost

Although the initial purchase cost may be higher than simple cold-galvanized products, the supplied cost assessment indicates that lifecycle costs can be reduced by more than 30% under applicable conditions due to lower maintenance and replacement requirements.

Integrated Procurement

Complete Components

ZHONGTIAN can supply U-channel steel, C-channel steel, ground piles, clamps, pressure blocks, and stainless-steel fasteners as an integrated procurement package.

Project Supply

Bundled sourcing helps EPC contractors and photovoltaic integrators reduce supplier coordination, logistics, inspection, and order management work.

Custom Processing

Custom Lengths

The Hot-Dip Galvanized U-Channel Steel Support Bracket supports custom lengths according to project drawings and installation requirements.

Custom Holes

Factory punching and positioning can be adjusted to match specific clamps, braces, rails, and connection components.

Pre-Cut Delivery

Components can be pre-cut and packed according to project sections, reducing onsite cutting and simplifying installation.

Frequently Asked Questions

What steel grades are available?

Q235B and Q355B hot-rolled U-channel steel are available. The selection depends on project loading and structural calculations.

What galvanizing standard is used?

The product follows GB/T 13912 requirements for hot-dip galvanized steel products.

Can it be used in coastal areas?

Yes. The galvanized coating is suitable for outdoor corrosion protection, including coastal and humid environments, when the coating specification is properly selected.

What is the angle range?

The standard adjustable range is 10° to 60%, subject to the final structural configuration.

Is onsite welding required?

No. The main structure uses standardized holes and bolt connections, reducing the need for onsite welding.

Can custom lengths be supplied?

Yes. ZHONGTIAN supports customized lengths, punching, bending, cutting, and other factory processing according to project requirements.
